CHRYSLER-FORCE OUTBOARD WIRING DIAGRAMS



CHRYSLER 35-50 HP MAGNETO IGNITION 1980-84
CHRYSLER 35-50 HP MAGNETO IGNITION w/ALTERNATOR
CHRYSLER 35-55 HP BATTERY IGNITION w/ALTERNATOR
CHRYSLER 55-65 HP MAGNAPOWER II IGNITION
CHRYSLER 55 HP CD IGNITION 1980-81
CHRYSLER 55 HP CD IGNITION 1982-84
CHRYSLER 75-105 HP BATTERY IGNITION with ALTERNATOR
CHRYSLER 75-135 HP MAGNAPOWER (DELTA) CD IGNITION with ALTERNATOR
CHRYSLER 70-135 HP MAGNAPOWER (MOTOROLA) CD IGNITION with ALTERNATOR
CHRYSLER 75-135 HP MAGNAPOWER (MOTOROLA II) CD IGNITION
CHRYSLER 75-135 HP MAGNAPOWER II CD IGNITION
CHRYSLER 75-85 HP MOTOROLA IGNITION 1980-84
CHRYSLER 3 & 4 cyl MAGNAPOWER BREAKERLESS CD IGNITION
CHRYSLER 115 & 140 HP MOTOROLA IGNITION 1980-84
CHRYSLER 125 HP PRESTOLITE IGNITION
FORCE 85 & 90 HP THRU 1991C MODELS  --  IGNITION SYSTEM
FORCE 90 HP 1991D thru 1995 MODELS
FORCE 120 & 125 HP THRU 1991A MODELS  --  IGNITION SYSTEM
FORCE 120 HP THRU 1991A MODELS  --  ENGINE WIRING
FORCE 120 HP 1991B thru 1995 MODELS  --  ENGINE WIRING
FORCE 120 HP 1996 - UP MODELS  --  ENGINE WIRING
FORCE 120 HP 1996 - UP MODELS  -- IGNITION SYSTEM
FORCE 125 HP THRU 1989 MODELS  --  ENGINE WIRING
