ELECTRICAL PARTS
4 THRU
50 HP
2 STROKE ONLY
Electrical
parts for Merc's OVER 50
HP
NOTE: SOME EARLY
MARINER MODELS ARE ACTUALLY YAMAHA MOTORS. THESE ARE NOT COVERED
HERE.
IF YOU HAVE A QUESTION AS TO
WHAT YOU HAVE PLEASE NOTE IN
CART COMMENT BOX. BE SURE TO INCLUDE YOUR
MOTOR'S SERIAL NUMBER IN
THE CART COMMENT BOX!
Please use your serial number to find the correct part. Mercury
does nothing by year
(the general year ranges below are for
rough reference only).
| DISTRIBUTOR DRIVE BELT |
DISTRIBUTOR DRIVE BELT
ALL MODELS |
 |
20140 |
$33.00
|
| MERCURY/U.S.
MARINER ELECTRICAL |
HP &
MODEL |
CYL |
YEAR |
SERIAL # |
SWITCHBOX |
STATOR |
TRIGGER |
RECTIFIER
REGULATOR |
4 GNAT
4 |
1 |
76-80
1980 |
9075839-UP
5598202-5595531 |
114-6222 |
174-6120K1 |
NA |
NA |
4
4.5 |
1 |
80-89
75-80 |
5595532-A855096
4107220-5595531 |
R336-4516 |
174-4469
(LOW SPEED)
174-4470
(HIGH SPEED) |
-NA |
NA- |
6, 8, 9.9, 10
S15 |
2 |
86-96
88-93 |
A197112-G289100 |
114-7452A3¹
114-7452K1¹ |
174-6617K1 |
R98450 |
-NA |
| 6, 8, 9.9 |
2 |
97-00 |
A197112-UP |
114-5713 |
174-6617K1 |
R98450 |
NA |
| 7.5 MODEL
75 |
2 |
72-73 |
3274633-
3801457 |
NA |
174-4469
(LOW SPEED)
174-4470
(HIGH SPEED) |
NA |
NA |
| 7.5 MODEL
75 |
2 |
74-86 |
3801458-
A197111 |
114-6222 |
174-6120K1 |
CALL |
154-6770 |
7.5, 9.8,
20 (MODEL 200) |
2 |
70-71 |
2810637-
3274632 |
IN STATOR |
174-3996 |
NA |
NA |
HP &
MODEL |
CYL |
YEAR |
SERIAL #
RANGE |
SWITCHBOX |
STATOR |
TRIGGER |
RECTIFIER
REGULATOR |
| 9.8 |
2 |
72-73 |
3263263-
3795658 |
R336-4516 |
174-4469
(LOW SPEED)
174-4470
(HIGH SPEED) |
NA |
NA |
9.8,
9.8 MODEL
110 |
2 |
74-78 |
3795659-
5206549 |
114-6222 |
174-6120K1 |
NLA |
154-6770 |
9.8,
9.8 MODEL
110 |
2 |
79-85 |
5206550-
UP |
114-6222 |
174-6120K1 |
NLA |
NA |
10
S15 |
2 |
86-96
88-93 |
A197112-0G289100
B238464-0G044365 |
114-7452K1 |
114-6617K1 |
R98450 |
NA |
| 10 |
2 |
97-00 |
0G760300-0G830999 |
114-5713 |
174-6617K1 |
R98450 |
NA |
| 15, S15, 20, 25 |
2 |
88-93 |
B238464-
0G044365 |
114-7452A3¹
114-7452K1¹ |
174-6617K1 |
NA |
NA |
| 15XD, S15 |
2 |
94-96 |
0G044027-
0G437999 |
114-4952 |
174-6617K1 |
R98450 |
154-6770 |
| 15XD, S15 |
2 |
96-97 |
0G438000-0G760299 |
114-7452K1 |
174-6617K1 |
R98450 |
154-6770 |
18
18 XD |
2 |
80-93
79-87 |
5837437-0G044026
58374367-B114230 |
114-7452A3 |
174-6617K1 |
R98450 |
NA |
HP &
MODEL |
CYL |
YEAR |
SERIAL #
RANGE |
SWITCHBOX |
STATOR |
TRIGGER |
RECTIFIER
REGULATOR |
| 20 MODEL 200 |
2 |
72-73 |
3226958-
3537530 |
R336-4516 |
174-4469
(LOW SPEED)
174-4470
(HIGH SPEED) |
NA |
NA |
| 20 MODEL 200 |
2 |
73-77 |
3537531-4709592 |
114-4911 |
R64638A1 |
R339-4996A1 |
NA |
| 20 |
2 |
77-80 |
4709593-5837436 |
114-6222 |
174-6120K1 |
R74324A3 |
NA |
| 20 |
2 |
80-87 |
5837437-B2384763 |
114-7452A3 |
174-6617K1 |
R98450A1 |
NA |
| 20, 25 |
2 |
88-94 |
0B238464-0G044026 |
114-7452K1 |
174-6617K1 |
R98450A1 |
NA |
| 20, 25 |
2 |
94-96 |
0G044027-
0G437999 |
114-4952 |
174-6617K1 |
R98450A1 |
154-6770 |
| 20 JET |
2 |
94-97 |
0G044027-
0G437999 |
114-4952 |
174-6617K1 |
R98450A1 |
154-6770 |
| 20 SEA PRO |
2 |
96-97 |
0G438000-
0G760299 |
114-7452K1 |
174-6617K1 |
R98450A1 |
154-6770 |
| 20 |
2 |
97-98 |
0G438000-
0G760299 |
114-4952 |
174-5721 |
R98450A1 |
154-6770 |
| 20, 25 |
2 |
98-00 |
0G760300-
UP |
114-5713 |
174-6617K1 |
R98450A1 |
154-6770 |
25
25 XD |
2 |
79-87 |
5705532-0B238463
5837437-B114230 |
114-7452A3 |
174-6617K1 |
R98450A1 |
NA |
HP &
MODEL |
CYL |
YEAR |
SERIAL #
RANGE |
SWITCHBOX |
STATOR |
TRIGGER |
RECTIFIER
REGULATOR |
30
ELECT. START |
2 |
94-96 |
0G053314-0G380074 |
114-7509 |
174-9710K1 |
134-9021-2 |
194-5279 |
30
ROPE
START |
2 |
98-00 |
0G590000-UP |
114-7509 |
174-9710K1 |
134-4512-3 |
NA |
| 30 JET |
3 |
89-97 |
C159200-0G589999 |
114-5772 |
174-5454K1 |
134-6452 |
154-6770 |
35 HP
ELECT. START |
2 |
84-89 |
6445633-B393190 |
114-7452A3 |
174-6617K1 |
R98450A1 |
154-6770 |
35 HP
ROPE START |
2 |
84-89 |
6445633-B393190 |
114-7452K1 |
174-6617K1 |
R98450A1 |
NA |
40 HP
(MODEL 400)
ELECT. START |
2 |
70-71 |
2874704-3336237 |
R332-4172 |
174-4424
incl. Rectifier |
NA
-- Use Stator
Kit -- |
154-6770 |
40 HP
(MODEL 402)
ELECT. START |
2 |
72-81 |
3336258-3899434 |
114-4911 |
174-5255 |
R338-4731A1 |
154-6770 |
40 HP
(MODEL 400)
ROPE START |
2 |
70-71 |
2874704-3336237 |
R332-4172 |
174-4424 |
NA |
NA |
HP &
MODEL |
CYL |
YEAR |
SERIAL #
RANGE |
SWITCHBOX |
STATOR |
TRIGGER |
RECTIFIER
REGULATOR |
40 HP MODEL
402
ROPE START |
2 |
72-81 |
3336258-4117709 |
114-4911 |
174-5255 |
R338-4731A1 |
NA |
40 HP
ELECT. START |
2 |
81-84 |
5823918-699999 |
114-7452A3 |
174-6617K1 |
R92431A1 |
154-6770 |
40 HP
ROPE START |
2 |
81-84 |
5823918-699999 |
114-7452A3 |
174-6617K1 |
R92431A6 |
NA |
40 HP
ELECT. START
40 JET |
4 |
89-91
89-97 |
C159200-D055047
C159200-0G589999 |
114-5772 |
174-5454K1 |
134-6452 |
154-6770 |
40 HP
ROPE START |
4 |
89-91 |
C159200-UP |
114-5772 |
174-5454K1 |
134-6452 |
NA |
40 HP
ELECT. START |
4 |
91-96 |
D055048-
0G291031 |
114-5772 |
174-9710K1 |
134-6452 |
194-5279 |
40 HP
ROPE START |
3 |
97-99 |
0G531301-0G760299 |
114-7509 |
174-9710K1 |
NA |
NA |
HP &
MODEL |
CYL |
YEAR |
SERIAL #
RANGE |
SWITCHBOX |
STATOR |
TRIGGER |
RECTIFIER
REGULATOR |
40 HP
ELECT. START |
3 |
97-99 |
0G531301-0G760299 |
114-7509 |
174-2075K1 |
134-4512-3 |
194-5279 |
45 HP
ELECT. START |
4 |
81-89 |
5531630-b393190 |
114-5772 |
174-5454K1 |
134-6452 |
154-6770 |
45 HP
ROPE START |
4 |
81-89 |
5531630-B393190 |
114-5772 |
R76314A3 |
134-6452 |
NA |
| 45 JET |
3 |
91-99 |
D000750-0G589999 |
114-9052 |
174-9710K1 |
134-9021-3 |
194-5279 |
50 HP
(MODEL 500) |
4 |
1967 |
2116318-2305100 |
114-2986 |
R398-2996 |
R393-2918 |
154-6770 |
50 HP
ELECT. START |
4 |
70-75 |
2858814-4357639 |
R333-3213 |
174-3175
(RED)
174-3176
(BLUE) |
NA |
154-6770 |
50 HP
ELECT. START |
4 |
76-85 |
4357640-
UP |
114-5772 |
174-5454K1 |
134-6452 |
154-6770 |
50 HP
ROPE START |
4 |
76-85 |
4357640-
UP |
114-5772 |
R76314A3 |
NA |
NA |
HP &
MODEL |
CYL |
YEAR |
SERIAL #
RANGE |
SWITCHBOX |
STATOR |
TRIGGER |
RECTIFIER
REGULATOR |
| 50 HP |
3 |
84-90 |
6428681-
D000749 |
114-7778 |
174-5454K1 |
134-6453 |
154-6770 |
50 HP
ELECT. START |
3 |
91-99 |
D000750-0G589999 |
114-9052 |
174-9710K1 |
134-9021-3 |
194-5279 |
50 HP
ROPE START |
3 |
97-99 |
0G531301-0G760300 |
114-7509 |
174-9710K1 |
NA |
NA |
50 HP
ELECT. START |
3 |
97-99 |
0G531301-0G833000 |
114-7509 |
174-2075K2 |
NA |
194-5279 |
| ¹ NOTE 1 For switchbox with stud & nut connections use 114-7452A3, for wire connections use 114-7452K1. |
Now that you have found what you need,
order it below. If your older motor is not listed or there is
a dash in the box, DON'T DESPAIR!
Many of these items are available
by special order or rebuilt, contact
us for details.
| MERCURY/MARINER ELECTRICAL |
| DESCRIPTION |
PART # |
PRICE |
SELECT |
| SWITCHBOX |
 114-7778 |
$203.00 |
|
STATOR
(RED 9 AMP)
(Example of
original) |
174-2075K1
Replaces EXISTING Mercury RED STATOR only |
Click for
larger image |
$227.00 |
|
STATOR
(RED 16 AMP)
(Example of
original) |
174-2075K2
Replaces EXISTING Mercury RED STATOR only |
Click for
larger image |
$227.00 |
|
| STATOR |
 174-3175
(RED COIL ONLY) |
$54.00 |
|
| STATOR |
 174-3176
(BLUE COIL ONLY) |
$43.00 |
|
| STATOR |
 174-3996 |
$257.00 |
|
| STATOR |
174-4424 |
$198.00 |
|
| STATOR |
R398-2996
(REPAIR & RETURN) |
$286.00 |
|
| STATOR |
174-5255 |
$216.00 |
|
| SWITCHBOX |
114-2986 |
$324.00 |
|
| SWITCHBOX |
114-4911 |
$225.00 |
|
| SWITCHBOX |
114-4952 |
$293.00 |
|
| SWITCHBOX |
114-4953 |
$311.00 |
|
| SWITCHBOX |
114-5713 |
$198.00 |
|
| SWITCHBOX |
114-5772 |
$276.00 |
|
| SWITCHBOX |
114-6222 |
$227.00 |
|
| SWITCHBOX |
114-7509 |
$69.00 |
|
| SWITCHBOX |
114-7452A3
with TERMINALS  |
$147.00 |
|
| SWITCHBOX |
114-7452K1
with WIRES  |
$184.00 |
|
| SWITCHBOX |
114-9052 |
$310.00 |
|
| SWITCHBOX |
R333-3213
(REPAIR & RETURN) |
$290.00 |
|
| SWITCHBOX |
R336-4516
(REPAIR & RETURN) |
$109.00 |
|
| SWITCHBOX |
R332-4172
(REPAIR & RETURN) |
$252.00 |
|
| LOW SPEED STATOR COIL ONLY |
174-4469 |
$34.00 |
|
| HIGH SPEED STATOR COIL ONLY |
174-4470 |
$34.00 |
|
| STATOR |
174-5454K1 |
$160.00 |
|
| STATOR |
174-5721 |
$120.00 |
|
| STATOR |
174-6120K1 |
$65.00 |
|
| STATOR |
174-6617K1 |
$133.00 |
|
| STATOR |
174-8778K1 |
$252.00 |
|
| STATOR |
174-9710K1 |
$257.00 |
|
| STATOR |
R64638A1
REPAIR & RETURN |
$181.00 |
|
| STATOR |
R76314A3
REPAIR & RETURN |
$184.00 |
|
| RECTIFIER |
154-6770 |
$43.00 |
|
| RECTIFIER |
194-5279 |
$142.00 |
|
| TRIGGER |
 134-6452
with Straight Arm
|
$86.00 |
|
| TRIGGER |
134-6453 |
$160.00 |
|
| TRIGGER |
134-4512-3 |
$76.00 |
|
| TRIGGER |
134-9021-2 |
$68.00 |
|
| TRIGGER |
134-9021-3 |
$99.00 |
|
| TRIGGER |
R338-4731A1
REPAIR & RETURN |
$84.00 |
|
| TRIGGER |
R92431A6
REPAIR & RETURN |
$80.00 |
|
| TRIGGER |
R98450
REPAIR & RETURN |
$72.00 |
|
| TRIGGER |
R338-4996A1
REPAIR & RETURN |
$88.00 |
|
| TRIGGER |
R74324A3
REPAIR & RETURN |
$95.00 |
|
| TRIGGER |
R393-2918
REPAIR & RETURN |
$265.00 |
|
Now that you have found what you need, please order it using the shopping cart above, the secure quick order form, or call in your order . We pay the freight out in USA on all orders over $100.00. Orders less than this amount will have a shipping and handling charge of $8.75 added. Some bulky and heavy items will incur additional charges. You will be notified beforehand if this is the case. Remember, all orders receive free technical support from the MasterTech! |
|
| |
Please review our Warranty, Returns & Refunds policies before you place an order.
DISCLAIMER
The information provided on these pages is correct to the best of my knowledge, however the MasterTech makes no warranty, express or implied, regarding the use of, results of, or liability created from, application of this data. This information is disseminated in good faith, however MasterTech assumes NO LIABILITY whatsoever in regard to this service. The information, software, products, and services published on this web site may include inaccuracies or typ0Graphical errors. Changes are periodically added to the information herein. Mastertech may make improvements to this site at any time. Parts ordered from this website may or may not be in dealer stock at the time of order. Thank you for reading.
Site best viewed at 1024 x 768 resolution or higher with Firefox 1.5-up, Netscape 6, or IE 5 or higher
© 1999-2010 MasterTech Marine
Revised 2-18-10
|
|
